Circuit Design

• CIP's primary goal is to strive for the "Best & Most Cost-Effective Design" based on the project requirements from customers. CIP designers have many years of hands-on design experience in embedded circuit, product development and project management.

Circuit Design Experience and Expertise

U Processor/U Controller	I/O Interface Experience	Programmable Logic
ARM Series	USB
TI DSP Families	Ethernet	CPLD
8051 Family	12C	FPGA
80X86	SPI	Actel
Analog Device	CAN	Xilinx
Microchip	RS-232/422	Altera
Atmel AVR Family	RS-485

How do we work with our customers?

• Customer's success is ours. As a company, we firmly believe long-term business relationship and trust comes from satisfactory results and on-time delivery.
• To achieve these goals, for each project, CIP design team will do a thorough engineering feasibility study, define project critical path, uncertainties, architecture, platform, EMI, FCC, UL compliance requirements, test plan and design trade-off before committing project delivery schedule. During development phase, CIP team communicates openly with customer the status of project critical milestones, issues and solutions. To ensure quality control through out the development cycle, CIP also provides prototype turnkey assembly service. CIP sources components closely with customers to meet the increasingly demand of time-to-market in the hi-tech industry today.

PCB layout and PCB Fabrication Services

• CIP Design provides quick turn PCB design and PCB fabrications. For urgent projects, CIP team operates 24 hours around the clock to help customers to meet time to market need and critical project development schedule. Our customer's success is ours. CIP is looking to establish long term and repeating business relationship with our customers.
• Our PCB layout strength lies in high density, high speed, analog, and wireless and noise sensitive PCB boards.
• CIP PCB design team has extensive experience in due with multi-gigahertz, impedance controlled, mixed signal, matched length and differential pairs.

PCB Design Capability

• -- Double Sided & Multilayer Designs
• -- High Speed Digital
• -- Digital, Analog, RF, Power, Mixed
• -- Impedance Control
• -- Matched Line Lengths
• -- Differential Pairs
• -- High density, small size
• -- Manufacturabilty & Design Rule check
• -- Backplanes
• -- Blind, Buried and Micro via(s)
• -- Buried Capacitance/Resistance

Standard Deliverables

• -- Gerber & Drill Files
• -- Fabrication & Assembly DXF Files
• -- SMT Stencil Files
• -- SMT Component Insertion Files
• -- PCB Max Files

Industrial Design

• -- Fully integrated 3D CAD design platform, Industrial Designers with many years of design experience
• -- Design for Manufacturabilty
• -- Converting customer's concept to a final amazing looking product
• -- Mechanical enclosure and chassis turnkey designs
• CIP provides innovative and creative designs with very fast turn time because of its design talents, strong technical rescources and extensive project management experience. With our fully integrated 3D CAD design platform, CIP's ID team coverts your initial concept to an amazing looking product. CIP conducts its research, artistic design, development and prototyping all under one roof.

Product Design

• CIP Design offers complete product design and development solution.
• -- Engineering feasibility study
• -- Electronic circuitry design
• -- PCB layout
• -- Industrial & enclosure design
• -- Firmware design
• -- Prototype test
• -- Prototype turnkey manufacturing
• -- Production
• Based on customer's preliminary specifications and functional descriptions, CIP Design team first conducts an in-depth engineering feasibility study to determine the best and the most cost-effective design follow with a detail project proposal. This first cut proposal outlines the initial proposed design specifications, project mile-stones, engineering budgetary cost, project master schedule, critical path (risk analysis), design trade-off, and architecture. In some cases, CIP Design team will suggest additional useful features and functions as a result of engineering feasibility study.

Industries

• -- Wireless communications
• -- Telecommunications
• -- Medical devices
• -- Test and Measurement systems: Fiber Optics and Electronics
• -- Optical components
• -- High Power
• -- RF
• -- Network Security

Turnkey Manufacturing Service

• CIP Design provides One Source, most cost-effective and professionally managed turnkey manufacturing service. CIP understands the pressure in the electronics industry to shorten time to market, product design and development time. CIP's goal is to provide customers the fastest turn time, highest quality and most cost-effective solution.

CIP's Advantages

• One Source Solution
• CIP has excellent engineering and diverse design resource. Our quick turn prototype and pre-production manufacturing process are well in place. One Source turnkey operation saves significant development time, cost, and reduces the risk of errors.
• Single-Point-Contact project management & most cost-effective solution
• Since CIP involves most of the design and development process (Circuit Design, PCB layout & Fabrication, BOM Sourcing, Industrial Design, Prototype Test and board assembly), the risks of miscommunications and delays among different design groups can all be reduced to its lowest level. A single-point-of -contact between a CIP's technical manager and customer's project manager is highly efficient and time saving.
• Error-Free transition from prototyping to pre-production phase
• CIP's One Source service also guarantees the error-free transition from prototype to pre-production. Because the final BOM(s), manufacturing special instructions, firmware code version, manufacturing test setup, mechanical enclosure specifications and final assembly documentation are all managed by the same project manager and manufacturing engineers.
• Time to Market
• CIP offers very quick turn prototype PCB fab and board assembly services. CIP's material engineers (EE) and managers help customers to review and verify specifications of each component listed in the BOM. Because CIP has an Asian Outsourcing Center, which is managed by experienced material engineering group, we are able to provide customers the most cost-effective and time to market manufacturing solution.
• State of the Art offshore electronic manufacturing facility
• Well-established outsourcing management Center CIP's Outsourcing Management Center employs 100+ full-time electronic and material engineers. Offshore project managers periodically audit PCB vendors and cost-effective component manufacturers to ensure customers of CIP get the highest quality products. CIP's small and mid-size customers, who tend to purchase in smaller QTY, can always get the very large QTY price by riding on the multi-billions purchasing power of CIP's offshore business partner.

CIP Manufacture Capabilities

• -- SMT/BGA
• -- Assembling
• -- Testing
• -- Reliability and Environmental Test

DSO Transition

Contact Us

•   CIP Design Inc.
•   32145 Alvarado-Niles Rd., Suite 208
•   Union City, CA 94587
•   Main: 510 456 6810
•   Fax: 510 793 8485
•
